KAWASAKI FX691V-CR00-S 1&18th” x 108.8MM CRANKSHAFT VERTICAL SHAFT ENGINE

Please note: Product photos are for illustration purposes only and the actual product may differ from that shown.

ENG8384

KAWASAKI FX691V-CR00-S

1&18th” x 108.8MM CRANKSHAFT

VERTICAL SHAFT ENGINE

Brand: KAWASAKI - GA

Please login to purchase

Extended Description

  • Description: Kawasaki FX691V-FS00-S, 22.0 hp (16.4 kW) Vertical Shaft Engine With A 1 1/8" x
  • 108.8 mm Crankshaft
  • Editorial: Major power and commercial-grade strength are on tap from the Kawasaki FX Series
  • engines. When you’re looking for power for your mower or heavy duty industrial
  • and construction equipment, you’ll find it here. All FX engines are Critical
  • Power SAE-Certified, compact, 90-degree V-twin engines. Every one features
  • hemispherical combustion chambers and overhead V-valve technology that helps ensure
  • low emissions, high power, and smooth operation.
  • Features: Overhead V-valve,
  • 90° V-twin,
  • Pressurized lubrication system,
  • Electronic spark ignition,
  • Automatic compression release,
  • Rotating metal grass chopper screen,
  • Multi-Stage canister air filter,
  • Cast-iron cylinder liners,
  • Metal engine cover with integrated clean out ports,
  • Heavy duty shift-type starter,
  • Type: Air cooled, 90 degree V-twin, normally aspirated petrol engine.
  • Engine: 726 cc
  • Engine (cc): 726 cc
  • Horsepower (@3,600 rpm): 22.0 hp (16.4 kW) at 3,600 RPM (Please Note: Horsepower rating as tested to SAE
  • J1995 Standards.)
  • Cylinder: Two, 90° V-twin.
  • Cylinder Liner: Cast-iron cylinder liners.
  • Bore x Stroke: 3.1 x 3.0 in. (78 x 76mm).
  • Displacement: 726 cc (44.3 cu. in.).
  • Compression Ratio: 8.2:1
  • Cooling: Forced air cooled. Fly-wheel fan.
  • Net Power: Maximum Power 22.0 hp (16.4 kW) at 3,600 RPM (Please Note: Horsepower rating as tested to SAE J1995 Standards.)
  • Net Torque: Maximum Torque 39.3 ft-lbs (53.2 N·m) at 2,200 RPM.
  • Decompressor: Automatic compression release.
  • Ignition: Electronic spark ignition.
  • Crankshaft Diameter: 1 1/8" x 108.8 mm (28.5 X 108.8 mm)
  • Air Filter: Multi-Stage canister air filter
  • Charging System: 12-volt.
  • Starter: 12-volt.
  • Exhaust/Muffler: No.
  • Fuel: Unleaded fuel - maximum of 10% ethanol in fuel.
  • Fuel Filter: Yes, replaceable, automotive-type.
  • Governor: Mechanical.
  • Oil Filter: Yes, spin-on engine oil filter.
  • Oil Capacity: Oil Capacity w/filter 2.2 U.S. qt ( 2.1 litres).
  • Dry Weight: (lb) 101.4 lbs.
  • Dry Weight: (kg) 46.0 kg.
  • Warranty: KAWASAKI COMMERCIAL ENGINE WARRANTY POLICY FOR AUSTRALIA
  • GA Power Equipment Spares warrants to the initial purchaser of each new Kawasaki
  • four-cycle engine that it will repair or replace, free of charge, any engine parts
  • found to be defective, under normal use and proper maintenance, for a period of
  • thirty-six (36) months, subject to the following conditions, exclusions,
  • obligations and limitations.
  • If you have questions about warranty coverage, please contact the local Kawasaki
  • dealer.
  • 1. COVERAGE.
  • a. Any factory-installed engine part found to be defective by Kawasaki within the
  • thirty-six (36) month warranty term shall be repaired or replaced without charge
  • for parts or labour at any authorized Kawasaki engine dealer located in Australia
  • b. A Kawasaki part or accessory sold and installed by an authorised Kawasaki Engine
  • Dealer, which is found defective in material and/or workmanship, within the three
  • (3) month warranty term, shall be repaired or replaced (at the option of Kawasaki)
  • without charge for the part or accessory, at any authorised Kawasaki Engine Dealer
  • located in Australia.
  • 2. OWNER’S OBLIGATIONS.
  • The following obligations must be fulfilled by owner to maintain the validity of
  • the Kawasaki warranty for Australia:
  • c. Owner must deliver the four-cycle engine to an authorized Kawasaki engine dealer
  • for inspection, maintenance services and adjustments according to the Periodic
  • Maintenance Chart for Australia (Right page). The inspection, maintenance services
  • and adjustments are to be performed at owner’s expense.
  • d. Owner must present proof of initial retail purchase date to an authorized
  • Kawasaki engine dealer at the time warranty repairs are performed on the four-cycle
  • engine.
  • 3. LIMITATIONS.
  • This warranty shall not apply to or include any of the following:
  • e. Repair or replacement required as a result of accident, misuse or neglect, lack
  • of reasonable and proper maintenance, repairs improperly performed or
  • replacements improperly installed, use of replacement parts or accessories not
  • conforming to Kawasaki specifications which adversely affect performance and/or
  • durability, alterations or modifications not recommended or approved in writing by
  • Kawasaki, and/or wear and deterioration occasioned by the use of the four-cycle
  • engine, the use of stale or incorrect fuel
  • f. Routine maintenance services, adjustments, cleaning and/or expendables such as
  • spark plugs, lubricants, oil filters, air filters, and fuel filters.
  • 4. LIMITED LIABILITY.
  • g. The liability of Kawasaki under the thirty-six (36) month warranty is limited
  • solely to the remedying of defects in factory-installed engine parts by an
  • authorized Kawasaki engine dealer at its place of business during customary
  • business hours. This warranty does not cover inconvenience or loss of use of the
  • four-cycle engine or transportation of the four-cycle engine to and from the
  • Kawasaki dealer. KAWASAKI SHALL NOT BE LIABLE FOR ANY OTHER EXPENSE, LOSS OR
  • DAMAGE, WHETHER DIRECT, INCIDENTAL, CONSEQUENTIAL OR EXEMPLARY ARISING IN
  • CONNECTION WITH THE SALE OR USE OF OR INABILITY TO USE THE KAWASAKI FOUR CYCLE
  • ENGINE FOR ANY PURPOSE.
  • h. NO EXPRESS WARRANTY IS GIVEN BY KAWASAKI WITH RESPECT TO THE KAWASAKI FOUR-CYCLE
  • ENGINE EXCEPT AS SPECIFICALLY SET FORTH HEREIN.
  • ANY WARRANTY IMPLIED BY LAW, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
  • FOR A PARTICULAR PURPOSE, IS EXPRESSLY LIMITED
  • TO THE THIRTY-SIX (36) MONTH WARRANTY TERM SET FORTH HEREIN. THE FOREGOING
  • STATEMENTS OF WARRANTY ARE EXCLUSIVE AND IN LIEU OF
  • ALL OTHER REMEDIES.
  • i. No distributor, dealer or other four-cycle engine reseller is authorized to
  • modify this Kawasaki Limited Four-Cycle Warranty.
  • AUSTRALIAN CONSUMER LAW (REG.90)
  • Our goods come with guarantees that cannot be excluded under the Australian
  • Consumer Law. You are entitled to a replacement or refund for a major failure and
  • for compensation for any other reasonably foreseeable loss of damage. You are also
  • entitled to have the goods repaired or replaced if the goods fail to be of
  • acceptable quality and the failure does not amount to a major failure.
  • The text above applies notwithstanding anything else expressed or implied to the
  • contrary in this Warranty document
  • Standard Pack Quantity: 1
  • Please Note: Specifications subject to change without notice.
  • International Standard: *PLEASE NOTE: Horsepower rating as tested to SAE J1995 Standards.*
  • Brand: Kawasaki,
  • Product Line: Engine, Four Stroke Engine, V-Twin Engine,
